مقدمة عن موازنة الاحمال (دمج خطوط)
متطلبات قبل تنفيذ الاسكربت :
تغيير اي بي اللست LAN الى اي بي منفذ خروج الشبكة
عمل نسخة احتياطية للروتر قبل نسخ الاسكربت
التأكد من استخدامك ip محلي الذي يشمل ال LIST -LAN1
الاسكربت كامل:
/ip firewall address-list
add list=LAN address=192.168.88.0/24
add address=172.16.0.0/12 comment=RFC6890 list=LAN1
add address=192.168.0.0/16 comment=RFC6890 list=LAN1
add address=10.0.0.0/8 comment=RFC6890 list=LAN1
add address=169.254.0.0/16 comment=RFC6890 list=LAN1
add address=127.0.0.0/8 comment=RFC6890 list=LAN1
add address=224.0.0.0/4 comment=Multicast list=LAN1
add address=198.18.0.0/15 comment=RFC6890 list=LAN1
add address=192.0.0.0/24 comment=RFC6890 list=LAN1
add address=192.0.2.0/24 comment=RFC6890 list=LAN1
add address=198.51.100.0/24 comment=RFC6890 list=LAN1
add address=203.0.113.0/24 comment=RFC6890 list=LAN1
add address=100.64.0.0/10 comment=RFC6890 list=LAN1
add address=240.0.0.0/4 comment=RFC6890 list=LAN1
add address=192.88.99.0/24 comment="6to4 relay Anycast [RFC 3068]" list=LAN1
/ip firewall mangle
add action=mark-connection chain=prerouting src-address-list=LAN dst-address-list=!LAN1 new-connection-mark=ISP1_conn passthrough=yes per-connection-classifier=src-address-and-port:2/0
add action=mark-connection chain=prerouting src-address-list=LAN dst-address-list=!LAN1 new-connection-mark=ISP2_conn passthrough=yes per-connection-classifier=src-address-and-port:2/1
add action=mark-routing chain=prerouting connection-mark=ISP1_conn src-address-list=LAN dst-address-list=!LAN1 new-routing-mark=conn1 passthrough=yes
add action=mark-routing chain=prerouting connection-mark=ISP2_conn src-address-list=LAN dst-address-list=!LAN1 new-routing-mark=conn2 passthrough=yes
/ip route
add distance=1 gateway=pppoe-out2
add distance=1 gateway=pppoe-out1 routing-mark=conn1
add distance=1 gateway=pppoe-out2 routing-mark=conn2
/interface list
add name=PPPOE
{
:foreach i in=[/interface pppoe-client find ] do={
:local a [/interface pppoe-client get $i name];
/interface list member add list=PPPOE interface=$a comment=salmandahmash;
}
}
/ip firewall raw
add action=drop chain=prerouting dst-port=53 in-interface-list=PPPOE protocol=tcp
add action=drop chain=prerouting dst-port=53 in-interface-list=PPPOE protocol=udp
انتهى الشرح ..
